Sentry three channel 'code hopping' 433Mhz radio control system for electric door openers

Sentry 433Mhz radio systems for use with electric door & gate openers

A Sentry three channel remote control receiver and transmitter kit will provide individual control of up to three electric garage door or gate operators from a single keyfob

Sentry receivers can be powered
from 12 or 24 volts AC or DC

Range approx 100mtrs

Three channel systems

French rolling code
receiver and keyfob identification: case has black front with red back

The French rolling code system has a 12 way DIP switch to provide up to 4096 code combinations and has no limit to the number of keyfob transmitters that can be used in the system.

SEN-R-R3 receiver with one SEN-R-T3 keyfob

Price � excl. VAT

Additional SEN-R-T3 keyfob
keyfob dimensions 66mm x 33mm x 14mm

Price � excl. VAT

Click image to enlarge

SEN-H-R3 receiver & SEN-H-T3 keyfob
(with cover removed)

Code hopping high security anti-scan technology
receiver and keyfob identification: case colour dark blue/grey

Note: a maximum of eight keyfobs
can be used on this system

SEN-H-R3 receiver with one SEN-H-T3 keyfob

Price � excl. VAT

Additional SEN-H-T3 keyfob
keyfob dimensions 66mm x 33mm x 14mm

Price: � excl. VAT

Fitting instructions for Sentry SEN-H-R3 receiver
(connections for SEN-R-R3 are similar)

Click image to enlarge

SEN-R-R1 receiver & SEN-R-T1 keyfob
(with cover removed)

Single channel systems

SEN-R-R1 receiver with one SEN-R-T1 keyfob

Price: � excl. VAT

Additional Sentry SEN-R-T1 keyfob
keyfob dimensions 66mm x 33mm x 14mm

Price: � excl. VAT

Click image to enlarge

SEN-H-R1 receiver & SEN-H-T1 keyfob
(with cover removed)

Code hopping high security anti-scan technology
receiver and keyfob identification: case colour dark blue/grey

Note: a maximum of eight keyfobs
can be used on this system
Fitting Instructions

SEN-H-R1 receiver with one SEN-H-T1 keyfob

Price: � excl. VAT

Additional Sentry SEN-H-T1 keyfob
keyfob dimensions 66mm x 33mm x 14mm

Price: � excl. VAT

International Marks of Approval

ETS 300 683 MPT 1340
EN 300 220-1 BAPT 2V125

These receivers may be connected to electric operators without external receiver power connections by using a separate 12 - 24 volt power supply and connection to the operator's wall button wiring (two wires)
