ANSA Door SystemsRS-1  Roller Door Remote Control System
Designed and manufactured in the UK

UK made

The ANSA RS-1 control unit is designed to operate roller garage doors powered by 240 volt single phase tubular drive motors.  The RS-1 control unit has all the features needed for efficient, safe and reliable operation of roller doors including an in-built remote control receiver which allows easy memorisation of up to fifteen ANSA 433Mhz high security 'keeloq' rolling code remote control transmitters an integral timed courtesy lamp, operating button and multi-function indicator LED.  An optional infra-red break-beam safety protection device may be fitted to the ANSA RS-1 control unit.

Click image to enlarge


ANSA RS-1 Roller Door Control System

Suitable for D.I.Y. Installation

•  Fitting Instructions  •

ANSA 'Metallo' keyfob transmitter
ANSA 'Metallo' keyfob transmitter with
slide cover to prevent accidental operation

The RS-1 can replace most makes
of roller door control unit including
the PDT system shown below:


PDT roller door control unit

  • An ideal upgrade solution in situations where replacement transmitters
    for an existing roller door control unit are no longer available.

  • Suitable for use with roller shutter doors powered by a conventional
    AC motor and controlled by two separate up & down 240 volt power feeds.

  • Compatible with existing photoelectric break-beam safety detectors
    from other roller door control units such as PDT etc.

  • The RS-1 control unit has an integral courtesy light which will illuminate the
    garage for 3½ minutes whenever the door is operated and turn off automatically.

  • Built-in control button which functions in the same way as the keyfob transmitter button.

  • The red LED on the control unit is a multifunction indication light, flashing rapidly when the optional infra-red break-beam safety protection device or light grid system is blocked and flashing slowly for fault detection.

  • Supplied with one ANSA 'Metallo' high security 'keeloq' rolling code keyfob which can provide individual control of up to three separate doors or gates with ANSA remote control systems.
    (a maximum of 15  keyfobs can be programmed)

  • Keyfob transmitter dimensions: 55mm x 30mm x 14mm (Metallo type with slide cover)

  • RS-1 control unit dimensions: 297mm x130mm x 74mm

  • Supplied with detailed & comprehensive installation instructions   (download requires adobe reader)

  • Options include a wireless external keyswitch or digital numeric entry keypad (see WK-1 & DK-14 below)

  • Receiver unit for gates and garage door operators also available click here for details

    Operation of the RS-1 roller door control unit is as follows:

  • To open the door, press the button on the keyfob transmitter for one second.
    The door will fully open and stop automatically at the fully open position.

  • To close the door, press the button on the keyfob transmitter for one second.
    The door will fully close and stop automatically at the fully closed position.

  • Pressing the button during a door opening or closing operation will instantly stop the
    door and pushing the button again for one second will reverse the original direction.

How to order:
Select the quantity of RS-1 control units required (one per door) and your desired quantity of additional keyfobs from the drop-down list and click 'Buy Now'

The total price for your selection
will be displayed at the checkout

ANSA RS-1 door control unit
including one 'Metallo' keyfob
our price: £
inc. VAT

 Enter quantity required

  Qty in stock:

Additional 'Metallo' keyfobs
our price: £
inc. VAT each
(special discount price when ordered
with an ANSA RS-1 control unit)

 Enter quantity required


Qty in stock:

order before 3pm for same day despatch



•  Product Reviews from our Customers  •

ANSA Door Systems

433Mhz radio control system with 'keeloq'
'rolling code' anti-scan technology
Range aprox. 50 to 75 mtrs

UK Home Office & CE approved for use in the UK and Europe

Conforms to MPT 1340 specification

CE


ANSA keyfobs & Accessories


Click image to enlarge
ANSA ATX-1 keyfob

ANSA AURiEL ATX-1 single button keyfob
'Keeloq' high security rolling code system for use
with a single ANSA 433Mhz remote control system
LR23A 12v battery included

our price for one: £ inc. VAT
2-4 qty price: £ each
5+ qty price: £
each
Qty in stock:

Qty:

Note: ANSA Metallo keyfob can be used an alternative to the ATX-1 keyfob


ANSA ATX-1 keyfob

ANSA AURiEL ATX-2 two channel keyfob
'Keeloq' high security rolling code system for use
with ANSA 433Mhz remote control systems, can
provide individual control of up to two doors
LR23A 12v battery included

our price for one: £ inc. VAT
2-4 qty price: £ each
5+ qty price: £
each
Qty in stock:

Qty:

Note: ANSA Metallo keyfob can be used an alternative to the ATX-2 keyfob

Note: The above ANSA AURiEL keyfobs are not compatible with Henderson branded keyfobs of similar appearance
due to a difference in the factory coding but we can obtain the Henderson version to special order >> email us

Click image to enlarge
ANSA 'Metallo' keyfob transmitter
ANSA 'Metallo' keyfob transmitter
with slide cover to prevent accidental operation

The Metallo can be used an alternative to the original ATX-1 & ATX-2
keyfobs above to provide individual control of up to three doors.

Features 'Keeloq' high security rolling code system for use
with ANSA 433Mhz remote control systems.

LR27A 12v battery included
dimensions 55mm x 30mm x 14mm

our price for one: £ inc. VAT
2-4 qty price: £ each
5-9 qty price: £ each
10+ qty price: £ each
Qty in stock:

Qty:


Click image to enlarge
ANSA WK-1 wireless key control switch
'Keeloq' high security rolling code system for use with ANSA
remote control systems, supplied with  fixing screws & 3 keys
Suitable for indoor or outdoor use
dimensions 74mm x 74mm x 45mm
price £ inc. VAT
Qty in stock:

Click image to enlarge
ANSA DK-14 wireless external digital numeric entry keypad
'Keeloq' high security rolling code system for use with ANSA
remote control systems, uses 4, 5 or 6 digit access number.
Metal operating buttons with blue night-time illumination.
Suitable for indoor or outdoor use
dimensions 80mm x 50mm x 40mm
price £ inc. VAT
Qty in stock:


Domino numeric
digital entry keypad
Domino external digital numeric entry keypad

The DOMINO keyless digital entry system is a simple
and secure way to open and close your garage door
without the need for a key or remote control

(three 'AA' batteries included)
Our Ref: DOMINO

price £ inc VAT
Qty in stock:
